Dr. Mach Soloflex - Page 46

Ceiling and wall attachment
Dr. Mach
Lamps and Engineering
Spare parts list
Item Qty. Name EDVNO Remark
49
50 1 Wall bearing 74841001 complete
51 1 Attachment set for wall bearing 74841002
52 1 Cover for wall bearing 74841003
53 1 Cover for wall bearing 74841004
54 1 Cap 74841005
55
56 1 Central spring arm Acrobat 2000
57 2 Cover for central spring arm
58 1 Sliding sleeve
59 2 Safety screw for central spring arm
60 1 Brake screw for central spring arm
61 2 Levelling washer 74011012
62 1 Gib washer 74011013
63 1 Circlip 74011014
64 2 Levelling washer 74011012
65 1 Sliding sleeve for semi-circular spring 53070208
66 1 Semi-circular spring 74011001
67 1 Helmet
68 1 Safety screw M4x10 DIN 7985 65152035
69 1 Serrated lock washer A4,3 DIN 6798 65592008
70 1 Standard spring arm Acrobat 2000
71 2 Cover for spring arm
72 4 (2) Fixing screw for cover
73
74 1 Cover
75
76 1 (2) Sliding contact complete with cabling 50223001
...28
Ceiling tube – 1 piece
Standard axis 2 arms– 2
pieces
Light-weighted central
axis 2 arms – 2 pieces
77 2 Sliding contact plug 67330002 Wall arm one only
78 2 Sliding contact sleeve 67330001 Wall arm one only
79 12 Washer 13 DIN 9021 galZn 65272001
80 12 Insulating washer 50281222
81 6(12) Retaining washer SK12 galZn ( ) with interm. flange
82
83
84
85
86 1 Transformer 40VA 67010205 Mach 120; Praxila ceiling
/ wall models
87 1 Transformer 120VA 67010202 Triaflex ceiling model
88 1 Toroid transformer 200VA
300VA 67010208
Trigenflex, Quintaflex,
Mach M3/380/400/500
ceiling models
89 1 Electronic transformer 50VA (not shown) 67010401 Mach 120 wall model
90 1 Canopy 50/420; height 110mm 50222207 Not shown
91 Flat canopy 50/450; height 60mm Not shown
92 Cylindric canopy 50/400; height 225mm
for camera
Not shown
93 Divided covering plate 50/450; 2mm thick 50281225 Not shown
95 Cylindric canopy 50/400; height 170mm
for camera
Not shown
59500001 Edition 06 11.03.2003 / Bak Page 46/48
