Ceiling and wall attachment
Dr. Mach
Lamps and Engineering
Spare parts list
Item Qty. Name EDVNO Remark
96 1 Space spring arm 74804001
74804002
97 1 Stop pin
98 1 Covering cap
99 2+8 Cover, 2-parted with screw M3x6 ULF 74012026
100 4 Screw M4x8 DIN 966
101 1 Screw M4x25 DIN 966 65112012
102 3 Screw M4x10 DIN 912 65052017
103 3 Serrated lock washer A4,3 DIN 6798 65592008
104 1 Semi-circular spring 74011001
105 1 Sliding sleeve for semi-circular spring 53070208
106 1 Cover for height adjustment until 2000
107 2 Cover 74012025 until 2000
108 1 Cover for spring force adjustment until 2000
109 1 Screw for pos. 108 until 2000
110 1 Sem-circular spring 74011001 until 2000
111 1 Sliding sleeve for semi-circular spring 53070208 until 2000
112 1 Securing screw M4x10 DIN 7985 65152035 until 2000
113 1 Central spring arm 74803002 until 2000
114 1 Extension arm stop for wall lamps incl. upper plas-
tic cover with cut-out
74829005 surcharge
59500001 Edition 06 11.03.2003 / Bak Page 47/48
