Dräger Polytron 7000 User Manual

41
Start-up
Example of info mode:
Screen 1
Instrument information
Line 1 – Date and time
Line 2 – Software version
Line 3 – Unit Part No.
Line 4 – Unit Serial No.
Line 5 – Unit code
Screen 2
Sensor information:
Line 1 – Sensor name
Line 2 – Sensor Part No.
Line 3 – Sensor Serial No.
Line 4 – EEPROM type
Line 5 – EEPROM version
Screen 3
Sensor configuration:
Line 1 – Gas name
Line 2 – Measuring range (can not be change) and unit of measurement
Line 3 – Measuring range for the analogue interface.
Displayed only, if the analogue interface card is installed
Line 4 – A1 alarm threshold and unit of measurement
1)
Line 5 – A2 alarm threshold and unit of measurement
1)
1) Displayed only if a relay module is fitted!
Screen 4
2)
Pump Infos:
Line 1 – Pump flow
Line 2 – Threshold error
Line 3 – Threshold warning
Line 4 – Pump run time
2) Displayed only if a pump module is fitted!
A009_en.eps
07.11.2011 12:34
SW Version
: 8.0
Part No.
: 8317778
Serial No.
: ARUA0001
DeviceCode: 00006317
Instrument Info
1/4
A010_en.eps
2/4
Sensorname: O2
Part No. : 6809630
Serial No.
: XXXXXXX
EEPROM Typ
: 1
EEPROM Vers.: 1
Sensor Info
A011_en.eps
3/4
Gasname : O 2
Range : 25.00 Vo
4–20 SP
: 25.00 Vo
Alarm A1
: 19.00 Vo
Alarm A2
: 23.00 Vo
Sensor Config.
A014_en.eps
4/4
Power : XXX %
Fault : X.X l/min
Warning : X.X l/min
Op.time : XXXX h
Pump info
