Dräger X-AM 5000 Technical Manual

9
What is What
Special symbols
Marking offset channels:
Fault message, refer to page 17
Warning message, refer to page 17
The peak value display for all measuring gases,
refer to page 17
The exposure evaluation display (TWA) for measuring gases, e.g., H
2
S and
CO,
refer to page 17
The exposure evaluation display (STEL) for measuring gases, e.g,. H
2
S and
CO,
refer to page 17
The device is set to function test with gas (bump test),
refer to page 40
The device is set to the fresh air calibration function,
refer to page 46
The device is set to the 1-button calibration function,
refer to page 47
The device is set to the single gas calibration function,
refer to page 50
The function for password entry is active,
refer to page 20
Battery / rechargeable battery 100 % full
Battery / rechargeable battery 2/3 full
Battery / rechargeable battery 1/3 full
Battery / rechargeable battery empty
Feature Reading on the display
ToxicTwins HCN+
CO H
2
compensation CO+

Dräger X-AM 5000 Specifications

General

Ingress Protection	IP67
Operating Humidity	10 to 95% RH, non-condensing
Detection Principle	Electrochemical, Catalytic, Infrared
Gases Detected	O2, CO, H2S, NO2, SO2, H2
Number of Gases	Up to 5
Display	Graphical LCD with backlight
Alarm Indicators	Audible, visual, and vibration alarms
Operating Temperature	-20 °C to +50 °C
Data Logging	Yes
Certifications	ATEX, IECEx, CSA
Response Time	T90 < 15 seconds (sensor dependent)
