LoRa Gateway User Manual ---Update:2017-02-21 42 / 44
12 Order Info
General Version:
 LG01P-433: LoRa Gateway best tune to 433 MHz.
 LG01P-868: LoRa Gateway best tuned to 868 MHz.
 LG01P-915: LoRa Gateway best tuned to 915 MHz
Screw Terminal Version:
 LG01S-433: LoRa Gateway best tune to 433 MHz.
 LG01S-868: LoRa Gateway best tuned to 868 MHz.
 LG01S-915: LoRa Gateway best tuned to 915 MHz.
Outdoor Version:
 OLG01-433: LoRa Gateway best tune to 433 MHz.
 OLG01-868: LoRa Gateway best tuned to 868 MHz.
 OLG01-915: LoRa Gateway best tuned to 915 MHz.
13 Packing Info
Package Includes:
 LG01P or LG01S LoRa Gateway x 1
 Stick Antenna for LoRa RF part. Frequency is one of 433 or 868 or 915Mhz depends the
model ordered
 Power Adapter: EU/AU/US type power adapter depends on country to be used
 Packaging with environmental protection paper box
Dimension and weight:
 Device Size: 12 x 8.5 x 3 cm
 Device Weight: 150g
 Package Size / pcs : 21.5 x 10 x 5 cm
 Weight / pcs : 360g
 Carton dimension: 45 x 31 x 34 cm. 36pcs per carton
 Weight / carton : 12.5 kg
14 Support
 Try to see if your questions already answered in the wiki.
 Support is provided Monday to Friday, from 09:00 to 18:00 GMT+8. Due to different
timezones we cannot offer live support. However, your questions will be answered as soon
as possible in the before-mentioned schedule.
 Provide as much information as possible regarding your enquiry (product models, accurately
describe your problem and steps to replicate it etc) and send a mail to
support@dragino.com
