Draytek Vigor2960 series - 4.2.2.1 Online Client Status

Vigor2960 Series User’s Guide
104
4
4
.
.
2
2
.
.
2
2
.
.
1
1
O
O
n
n
l
l
i
i
n
n
e
e
C
C
l
l
i
i
e
e
n
n
t
t
S
S
t
t
a
a
t
t
u
u
s
s
This page displays general information for PPPoE server; allows you to disconnect the
network connection to PPPoE server.
Each item will be explained as follows:
Item Description
Disconnect
Click it to disconnect the profile connection.
Auto Refresh
Specify the interval of refresh time to obtain the latest status.
The information will update immediately when the Refresh
button is clicked.
Refresh
Renew current web page.
MAC Address
Display the MAC address of the client’s host.
User Name
Display the user name used to access into the PPPoE server.
IP Address
Display the IP address of the client’s host.
Up Time
Display the time that the PPPoE connection built.
RX Bytes
Display the total amount of received packets.
TX Bytes
Display the total amount of transmitted packets.
