Vigor2960 Series User’s Guide
90
period of low traffic. Click Enable to activate the
power/energy saving function if required..
Apply – Click it to save and exit the dialog.
Cancel – Click it to exit the dialog without saving anything.
Refresh
Renew current web page.
Interface
Display the name of the WAN port on the router.
Enable
Display the status of the profile. False means disabled; True
means enabled.
Duplex
Display the duplex used (full or half) by such profile.
Speed
Display the transmission rate (e.g., 1000M) for such
interface.
802.3az
Display such function is enabled or disabled.
4
4
.
.
2
2
L
L
A
A
N
N
Local Area Network (LAN) is a group of subnets regulated and ruled by router. The design
of network structure is related to what type of public IP addresses coming from your ISP.
The most generic function of Vigor router is NAT. It creates a private subnet of your own.
As mentioned previously, the router will talk to other public hosts on the Internet by using
public IP address and talking to local hosts by using its private IP address. What NAT does
is to translate the packets from private IP address to public IP address to forward the right
packets to the right host and vice versa. Besides, Vigor router has a built-in DHCP server
that assigns private IP address to each local host.
