Vigor2960 Series User’s Guide
320
4
4
.
.
9
9
.
.
6
6
V
V
P
P
N
N
P
P
r
r
o
o
f
f
i
i
l
l
e
e
s
s
The router allows you to create VPN profiles via the protocol of IPsec or PPTP (dial-in or
dial-out).
The router supports up to 200 VPN tunnels simultaneously. The following figure shows the
summary table.
4
4
.
.
9
9
.
.
6
6
.
.
1
1
I
I
P
P
s
s
e
e
c
c
T
T
u
u
n
n
n
n
e
e
l
l
Display the name of LAN to LAN profile with IPsec policy.
Each item will be explained as follows:
Item Description
Add
Add a new profile.
Edit
Modify the selected profile.
To edit a profile, simply select the one you want to modify
and click the Edit button. The edit window will appear for
you to modify the corresponding settings for the selected
profile.
Delete
Remove the selected profile.
To delete a profile, simply select the one you want to delete
and click the Delete button.
Refresh
Renew current web page.
Profile Number Limit
Display the total number (200) of the object profiles to be
created.
Profile
Display the name of LAN to LAN profile with IPsec policy.
Enable
Display the status of the profile. False means disabled; True
means enabled.
Dial-Out Through
Display the WAN interface selected for the profile.
Local IP / Subnet Mask
Display the LAN IP address with subnet mask of this profile.
