Vigor2960 Series User’s Guide
125
4
4
.
.
3
3
.
.
2
2
S
S
t
t
a
a
t
t
i
i
c
c
R
R
o
o
u
u
t
t
e
e
When there are several subnets in LAN, a more effective and quicker way for connection is
static route rather than other methods. Simply set rules to forward data from one specified
subnet to another specified subnet.
4
4
.
.
3
3
.
.
2
2
.
.
1
1
S
S
t
t
a
a
t
t
i
i
c
c
R
R
o
o
u
u
t
t
e
e
The router offers IPv4 and IPv6 for you to configure the static route. Both protocols bring
different web pages.
Each item will be explained as follows:
Item Description
Add
Add a new static route setting.
Edit
Modify the selected static route setting.
To edit static route setting, simply select the one you want to
modify and click the Edit button. The edit window will
appear for you to modify the corresponding settings for the
selected rule.
Delete
Remove the selected static route setting.
To delete a static route setting, simply select the one you
want to delete and click the Delete button.
Rename
Allow to modify the selected profile name.
Refresh
Renew current web page.
Profile Number Limit
Display the total number of the profiles to be created.
Profile
Display the name of such static route.
Enable
Display the status of the profile. False means disabled; True
means enabled.
Destination IP Address
Display the IP address for such static route profile.
Subnet Mask
Display the subnet mask for such static route profile.
To Next Page
