Vigor2960 Series User’s Guide
374
4
4
.
.
1
1
3
3
.
.
2
2
Q
Q
o
o
S
S
R
R
u
u
l
l
e
e
There are 32 filter rules that can be configured in such page for incoming and outgoing data.
4
4
.
.
1
1
2
2
.
.
2
2
.
.
1
1
Q
Q
o
o
S
S
R
R
u
u
l
l
e
e
Available parameters are listed as follows:
Item Description
Add
Add a new rule profile.
Edit
Modify the selected profile.
To edit a profile, simply select the one you want to modify
and click the Edit button. The edit window will appear for
you to modify the corresponding settings for the selected
profile.
Delete
Remove the selected profile.
To delete a profile, simply select the one you want to delete
and click the Delete button.
Rename
Allow to modify the selected profile name.
Refresh
Renew current web page.
Profile
Display the name of the profile for the filter.
Profile Number Limit
Display the total number (32) of the profiles to be created.
Enable
Display the status of the profile. False means disabled; True
means enabled.
Local IP Object
Display the source IP address for the filter.
Remote IP Object
Display the destination IP address for the filter.
Service Type
Display the service type (e.g., IKE, HTTP, AUTH and etc)
for the filter.
Match Type
Display the match type (e.g., TOS or DSCP) for the filter.
