Draytek Vigor2960 series User Manual

Vigor2960 Series User’s Guide
120
Available parameters are listed as follows:
Item Description
Profile
Type a name for such profile.
Status
Check the box to enable such profile.
Domain Name
Type the domain name for such profile.
Alias Domain Name
Type several domain names in this field. LAN DNS will
redirect both Domain name and Alias Domain Name to an
assigned IP.
For example, Domain Name is set with “www.draytek.com”,
and the Alias Domain Name is set as “www.dray.com”. If
the IP address is set with “192.168.1.123”, then both
“www.draytek.com” and “www.dray.com” will be directed
to “192.168.1.123”.
Type
When you choose IP, you need to type IP address and/or
IPv6 address as the mapping target.
When you choose CNAME, you need to type the content
(domain) of CNAME as the mapping target.
Please choose the suitable type to determine which IP
address or CNAME will be mapped by the above domain
name/alias domain name.
IP Address
Type the IP address in this field. Then, the above domain
and/or alias domain name will be mapped to such IP address.
IPv6 Address
Type the IPv6 address in this field. Then, the above domain
and/or alias domain name will be mapped to such IPv6
address.
CNAME
Type another domain name in this field. Then, the above
domain and/or alias domain name will be mapped to such
specified domain.
Applied to
LAN DNS can be applied to specified LAN interfaces or all
of the LAN interfaces.
LAN Profile – When you choose Specified LANs, it is
necessary to specify at least one LAN profile in this field.
Apply
Click it to save and exit the dialog.
Cancel
Click it to exit the dialog without saving anything.
4. Enter all of the settings and click Apply. The new profile will be added on the screen.

Draytek Vigor2960 series Specifications

General

Brand	Draytek
Model	Vigor2960 series
Category	Firewall
Language	English
