Vigor2960 Series User’s Guide
210
H
H
o
o
w
w
t
t
o
o
c
c
r
r
e
e
a
a
t
t
e
e
a
a
n
n
e
e
w
w
S
S
e
e
r
r
v
v
i
i
c
c
e
e
T
T
y
y
p
p
e
e
O
O
b
b
j
j
e
e
c
c
t
t
p
p
r
r
o
o
f
f
i
i
l
l
e
e
1. Open Objects Setting>> Service Type Object.
2. Simply click the Add button.
3. The following dialog will appear.
Available parameters are listed as follows:
Item Description
Profile
Type a name for such profile. The number of the characters
allowed to be typed here is 10.
Protocol
Specify one of the protocols for such profile.
Source Port Start
It is available for TCP/UDP protocol. It can be ignored for
ICMP.
Type a port number (0 – 65535) as the starting source port.
Source Port End
It is available for TCP/UDP protocol. It can be ignored for
ICMP. Type a port number (0 – 65535) as the ending source
port.
Destination Port
Start
It is available for TCP/UDP protocol. It can be ignored for
ICMP.
Type a port number (0 – 65535) as the starting destination
port.
Destination Port
End
It is available for TCP/UDP protocol. It can be ignored for
ICMP. Type a port number (0 – 65535) as the ending
destination port.
Apply
Click it to save the configuration.
Cancel
Click it to exit the dialog without saving anything.
4. Enter all of the settings and click Apply.
