Vigor2960 Series User’s Guide
291
The following page is used to create Active-Standby profiles.
Available parameters are listed as follows:
Item Description
Add
Add a new HA profile.
Edit
Modify the selected HA profile.
To edit the profile, simply select the one you want to modify
and click the Edit button. The edit window will appear for you
to modify the corresponding settings for the selected profile.
Delete
Remove the selected HA profile.
To delete a profile, simply select the one you want to delete and
click the Delete button.
Refresh
Renew current web page.
Auto Refresh
Specify the interval of refresh time to obtain the latest status.
The information will update immediately when the Refresh
button is clicked.
Profile Number Limit
Display the total number (4) of the object profiles to be created.
Profile
Display the name of the HA profile.
HA LAN Profile
Display the LAN profile used by such HA.
Virtual IP for
Gateway
Display the IP address of the gateway.
VHID
Display the virtual host ID number of the profile.
Role
Display the role of this profile in the corresponding HA group.
HA Status
Display the online status (Master, Backup, LAN_failed and
WAN_Failed) of such HA profile.
