Vigor2960 Series User’s Guide
315
LDAP profiles
Choose a LDAP profile for PPTP Server if LDAP is selected
as user authentication type.
To clear the selected one, click
to remove current object
selections.
DHCP from
Choose a LAN profile for L2TP Server if RADIUS is
selected as user authentication type.
DHCP Relay
Enable - Let the router assign IP address to every host in the
LAN.
Disable - Let you manually assign IP address to every host
in the LAN.
PPTP MSS
Type the maximum segment size (MSS) for PPTP VPN
tunnel.
NetBIOS Naming
Packet
Pass – Click it to have an inquiry for data transmission
between the hosts located on both sides of VPN Tunnel
while connecting.
Block – When there is conflict occurred between the hosts
on both sides of VPN Tunnel in connecting, such function
can block data transmission of Netbios Naming Packet inside
the tunnel.
Multicast Packet via
VPN
Some programs might send multicast packets via VPN
connection.
 Pass – Click this button to let multicast packets pass
through the router.
 Block – This is default setting. Click this button to let
multicast packets be blocked by the router.
PPTP Acceleration
Enable – Click it to make PPTP acceleration for VPN.
Apply
Click it to save the configuration.
Cancel
Click it to discard the settings configured in this page.
4
4
.
.
9
9
.
.
4
4
.
.
2
2
L
L
2
2
T
T
P
P
This page display current status for VPN tunnel built with L2TP protocol.
