Vigor2960 Series User’s Guide
322
profile.
Failover to – Choose a wan profile which will lead the data
passing through other WAN automatically when the selected
WAN interface (in Dial-Out Through) is failover.
Local IP/Subnet - Type the IP address and subnet mask of
local host.
Local Next Hop - Specify the gateway for WAN interface.
Usually, use the default setting (leave it in blank).
Remote Host - Type the WAN IP address for the remote
host.
Remote IP / Subnet Mask - Type the LAN IP address and
LAN subnet mask for the remote host.
More Remote Subnet – Add more remote subnet in this
field if required.
IKE Phase 1 - Select from Main mode and Aggressive
mode. The ultimate outcome is to exchange security
proposals to create a protected secure channel. Main mode is
more secure than Aggressive mode since more exchanges
are done in a secure channel to set up the IPsec session.
However, the Aggressive mode is faster. The default value
in Vigor router is Main mode.
Auth Type - The authentication to be used by Pre-Shared
Key or RSA Signature. Choose PSK or RSA for such
profile.
Local Certificate - Choose a local certificate from the drop
down list if RSA is selected as Auth Type.
Local Peer ID –Type the ID for Vigor2960 which can be
configured by the remote end. It is available for Aggressive
Mode enabled only.
Remote Peer ID – Peer ID is on behalf of the IP address
while identity authenticating with remote VPN server. The
length of the ID is limited to 47 characters. It is available for
Aggressive Mode enabled only.
Preshared Key – Specify a key for IKE authentication if
PSK is selected as Auth Type.
Security Protocol – Choose ESP to specify the IPsec
protocol for the Encapsulating Security Payload protocol.
The data will be encrypted and authenticated. Choose AH to
specify the IPsec protocol for the Authentication Header
protocol. The data will be authenticated but not be
encrypted.
Apply
Click it to save the configuration.
Cancel
Click it to exit the page without saving the configuration.
