Vigor2960 Series User’s Guide
63
length:7)
Enable
Check this box to enable such profile.
Description
Give the brief description for such profile.
Port
Display the physical WAN interface for such profile.
Default MAC
Address
Enable – Click it to enable the default MAC address for
such profile.
Disable – Click it to type the MAC address manually for
such profile.
MAC Address - Specify the MAC address for such profile if
you click Disable for Default MAC address. In default, the
system will determine it automatically.
IPv4 Protocol
There are four connection modes for you to specify for IPv4
protocol type. Each mode will bring up different web page.
Mode
Determine such profile will be used for NAT or routing.
IPv6 Protocol
There are five connection modes for you to specify for IPv6
protocol type. Each mode will bring up different web page.
Enable Schedule
Reconnect
Enable – Click it to enable the function of reconnecting the
network automatically within the time schedule.
Schedule Time Object - Choose the time object profile
to be applied by such WAN.
Disable – Click it to disable the schedule reconnect function.
VLAN Tag
Enable – Click it to enable the function of VLAN Tag. Data
transmitted through the router will be tagged with specified
number for identification.
Disable – Click it to disable the function of VLAN Tag.
