VigorAP 900 User’s Guide
74
IGMP Snooping
Check this box to enable this function. Multicast traffic will be
forwarded to ports that have members of that group. Disabling
IGMP snooping will make multicast traffic treated in the same
manner as broadcast traffic.
Mac Clone
Check this box and manually enter the MAC address of the
device with SSID 1. The MAC address of other SSIDs will
change based on this MAC address.
Channel
Means the channel of frequency of the wireless LAN. You may
switch channel if the selected channel is under serious
interference. If you have no idea of choosing the frequency,
please select AutoSelect to let system determine for you.
Extension Channel
With 802.11n, there is one option to double the bandwidth per
channel. The available extension channel options will be varied
according to the Channel selected above. Configure the
extension channel you want.
Rate
If you choose 11g Only, 11b Only or 11n Only, such feature
will be available for you to set data transmission rate.
Phy Mode
Data will be transmitted via HTMIX mode.
Each access point should be setup to the same Phy mode for
connecting with each other.
Subnet
Choose LAN-A or LAN-B for each SSID.
Security
Select Disabled, WEP, TKIP or AES as the encryption
algorithm.
Peer Mac Address
Four peer MAC addresses are allowed to be entered in this
page at one time.
Packet-OVERDRIVE
This feature can enhance the performance in data transmission
about 40%* more (by checking Tx Burst). It is active only
when both sides of Access Point and Station (in wireless
client) invoke this function at the same time. That is, the
wireless client must support this feature and invoke the
function, too.
Note: Vigor N61 wireless adapter supports this function.
Therefore, you can use and install it into your PC for matching
with Packet-OVERDRIVE (refer to the following picture of
Vigor N61 wireless utility window, choose Enable for
