VigorAP 900 User’s Guide
75
TxBURST on the tab of Option).
Antenna
VigorAP 900 can be attached with two antennas to have good
data transmission via wireless connection. However, if you
have only one antenna attached, please choose 1T1R.
Tx Power
The default setting is the maximum (100%). Lowering down
the value may degrade range and throughput of wireless.
Channel Width
20 MHZ- the device will use 20Mhz for data transmission and
receiving between the AP and the stations.
Auto 20/40 MHZ– the device will use 20Mhz or 40Mhz for
data transmission and receiving according to the station
capability. Such channel can increase the performance for data
transmission.
After finishing this web page configuration, please click OK to save the settings.
