VigorAP 910C User’s Guide
169
Each item is explained as follows:
Item Description
SSID
Display the SSID of the AP scanned by VigorAP 910C.
BSSID
Display the MAC address of the AP scanned by VigorAP
910C.
RSSI
Display the signal strength of the access point. RSSI is the
abbreviation of Received Signal Strength Indication.
Channel
Display the wireless channel used for the AP that is scanned by
VigorAP 910C.
Encryption
Display the encryption mode for the scanned AP.
Authentication
Display the authentication type that the scanned AP applied.
Scan
It is used to discover all the connected AP. The results will be
shown on the box above this button
AP’s MAC Address
If you want the found AP applying the WDS settings, please
type in the AP’s MAC address.
AP’s SSID
To specify an AP to be applied with WDS settings, you can
specify MAC address or SSID for the AP. Here is the place
that you can type the SSID of the AP.
Select as Universal
Repeater
In Universal Repeater mode, WAN would work as station
mode and the wireless AP can be selected as a universal
repeater. Choose one of the wireless APs from the Scan list.
