Draytek VigorAP 910C User Manual

VigorAP 910C User’s Guide
34
Such feature is available for WEP/802.1x mode.
After finishing this web page configuration, please click Next to continue.
2
2
.
.
7
7
.
.
4
4
C
C
o
o
n
n
f
f
i
i
g
g
u
u
r
r
i
i
n
n
g
g
5
5
G
G
H
H
z
z
W
W
i
i
r
r
e
e
l
l
e
e
s
s
s
s
S
S
e
e
t
t
t
t
i
i
n
n
g
g
s
s
Such page is available when AP is selected as Operation Mode. VigorAP 910C offers 5GHz
wireless connection capability. You can setup 5GHz features in Quick Start Wizard first.
Once the USB 5GHz wireless dongle connects to VigorAP 910C, it can work immediately.
Available settings are explained as follows:
Item Description
Operation Mode
Choose AP or Universal Repeater as the Operation Mode.
Wireless Mode
At present, VigorAP 910C can connect to 11a only, 11n only
(5G), Mixed (11a+11n) and Mixed (11a+11n+11ac) stations
simultaneously. Simply choose Mixed (11a+11n+11ac) mode.
Main SSID
Set a name for VigorAP 910C to be identified.
Multiple SSID – You can specify subnet interface for SSID2 ~
SSID4.
Channel
Means the channel of frequency of the wireless LAN. The
default channel is 36. You may switch channel if the selected
channel is under serious interference.
Station List
Click the Display button to open the Station List dialog. It
provides the knowledge of connecting wireless clients now
along with its status code.
AP Discovery
Click the Display button to open the AP Discovery dialog.
VigorAP 910C can scan all regulatory channels and find
working APs in the neighborhood.
This option is not available when AP is selected as the
Operation Mode.
