The downstream or upstream from FTP, HTTP or some P2P applications will occupy large
of bandwidth and affect the applications for other programs. Please use Bandwidth
Management to make the bandwidth usage more efficient.
Available settings are explained as follows:
Item Description
SSID
Display the specific SSID name of the AP.
Enable
Check this box to enable the bandwidth management for clients.
Upload Limit
Define the maximum speed of the data uploading which will be
used for the wireless stations connecting to Vigor AP with the
same SSID.
Use the drop down list to choose the rate. If you choose User
defined, you have to specify the rate manually.
Download Limit
Define the maximum speed of the data downloading which will
be used for the wireless station connecting to Vigor AP with the
same SSID.
Use the drop down list to choose the rate. If you choose User
defined, you have to specify the rate manually.
Auto Adjustment
Check this box to have the bandwidth limit determined by the
system automatically.
Total Upload Limit
When Auto Adjustment is checked, the value defined here will
be treated as the total bandwidth shared by all of the wireless
stations with the same SSID for data uploading.
Total Download
Limit
When Auto Adjustment is checked, the value defined here will
be treated as the total bandwidth shared by all of the wireless
stations with the same SSID for data downloading.
After finishing this web page configuration, please click OK to save the settings.
