VigorSwitch P1085 User’s Guide
69
Time and Date Display the time and date information related to the selected
device.
- Click it to modify the time setting for the device.
Device Action Display the action performed by IP-based device.
Factory Default - Click the Apply button to rest the factory
default to the IP device.
Reboot - Click the Apply button to reboot the IP device
immediately.
Device Ping Check -- Configure settings for ping check of IP camera or NVR.
Port Display the port number of the IP device
Enable Enable - Click it to enable the device ping check function.
Disable - Click it to disable the function.
Ping IP Address Add Device - Click it to add an IP address of the device to be
pinged by VigorSwitch. Up to 16 IP address(es) can be added
and displayed in this field one by one (with the format of
x.x.x.x, x.x.x.x, x.x.x.x...)
Del Device - Click it to remove the selected IP address.
Interval Time (sec) Set a time interval (15, 30, 60, 120) for pinging action.
Retry Time Choose 1, 3, or 5 for Vigor system to retry the pinging action.
Failure Action Configure the power behavior for each LAN port.
Power Cycle - Once the device is offline, Vigorswitch will
power off the device and then power on the device again.
Power Off - When the device is offline, power off the device
immediately.
Nothing - When the device is offline, no action will be
Note: When a PoE hub connecting to LAN port of VigorSwitch,
the power behavior (on/off) to the PoE hub also will apply to
all the devices connecting to the PoE hub.
Mail Alert Enable - When the device is offline, Vigor system will send an
alert mail to notify the receiptant.
Mail with Snapshot - If enabled, the switch will try to get
snapshot from the device per half hour. Before using this
