4UBUVTTDSFFO
Table 41-1:
Status screen (continued)
Menu item Default value
Minimum
value
Maximum
value
Units Notes
High probe signal* -- 0 4000 counts
Systems using tap or softened water control water levels
electronically using a three-rod probe. The controller initiates the
following events when the probes are in contact with water:
High probe: Fill valve closes
Mid probe: Fill valve opens
Low probe: Low water cut-off
The display indicates the probe is in contact with water by indicating
“Water” or “No water.”
The high, mid, and low probe signal counts, displayed on the Status
screen, indicate:
<800 = Probe is properly reading water
800-1200 = Faulty water probe (causes a “Faulty water probe”
alarm) 1200-1600 = Probe requires maintenance (causes a “Clean
probes” message)
>1600 = Probe is dry
High water probe* -- No water Water --
Mid probe signal* -- 0 4000 counts
Mid water probe* -- No water Water --
Low probe signal* -- 0 4000 counts
Low water probe* -- No water Water --
DI low water
switch*
-- No water Water --
Airflow switch -- Flow No flow --
Interlock switch -- Open Closed --
Water until
drain/flush*
-- 0 2,200,000 lbs
Displays amount of water to be converted to steam before automatic
drain sequence (ADS) can begin
-- 0 1,000,000 kg
Water until service
-- 0 2,200,000 lbs
Displays amount of water to be converted to steam before next
recommended maintenance service
-- 0 1,000,000 kg
Hours until service -- 0 10,000 hours XT systems only
Lifetime hours -- 0 100,000 hours XT systems only
Blower 1 tach -- 0 7000 rpm Displays rotation speed of Blower 1 (GTS systems only)
Blower 2 tach -- 0 7000 rpm Displays rotation speed of Blower 2 (GTS systems only)
Blower 3 tach -- 0 7000 rpm Displays rotation speed of Blower 3 (GTS systems only)
Blower 4 tach -- 0 7000 rpm Displays rotation speed of Blower 4 (GTS systems only)
Gas valve 1 -- Open Closed -- GTS systems only
Gas valve 2 -- Open Closed -- GTS systems only
Gas valve 3 -- Open Closed -- GTS systems only
Gas valve 4 -- Open Closed -- GTS systems only
Combust air switch -- Flow No Flow -- GTS systems only
Power vent switch -- Open Closed -- GTS systems only
Flue pressure switch -- Open Closed -- GTS systems only
Low water sensor -- No water Water -- GTS systems only
Current -- 0
Model
dependent
Amps XT systems only
High water probe -- No water Water -- XT systems only
Current 2 -- 0
Model
dependent
-- Right cylinder of 2-cylinder model, XT systems only
High water probe 2 -- No water Water Amps Right cylinder of 2-cylinder model, XT systems only
* Not an XT menu item
Operation
