1BHFt%3*45&&.7BQPSMPHJD*OTUBMMBUJPOBOE0QFSBUJPO.BOVBM
Table 45-1:
Diagnostics menu (continued)
Menu item Default value
Minimum
value
Maximum
value
Units Description
Test outputs (continued)
Contactor 1, 2, 3, or 4 -- -- -- --
Cycles output to verify operation.
SSR control --------
Ignition module 1, 2, 3, or 4 -- -- -- --
Blower speed control -- -- -- --
Power vent control -- -- -- --
Steam valve --------
Test run*
Test run percent 0 0 100 % Set demand percent value between 0 and 100 to test.
Test run time 0 0 30 minutes Set test run time duration between 0 and 30 minutes.
Start
Stop
* Humidifier test run will not occur if safety circuits (for example, duct high limit switch, airflow proving switch, or safety interlock switch ) are not operating
correctly.
Continued
