EXT 1824G User’s Manual 4. Detector Component
EXT 1824G-UM-COM-EN-03 25
4.2.2. Battery Pack
4.2.2.1. Battery Pack Specification
Table 4.3. Battery Charger Specifications
Item Description
Model EVS-MBP-Y
Cell Type Lithium Polymer
Number of Cells 2S1P (2series 1 Parallel)
Rated Power Supply Output : DC +7.4 V
Lifetime Approx. 500 cycles of use (full charge to discharge is 1 cycle)
Dimensions (W x H x D) 163 mm x 148 mm x 7 mm
Weight 0.24 kg
4.2.2.2. Battery Pack Components
Figure 4.3. Battery Pack
A. Charging indicator : Indicates the charging status
B. Latch knob : Rotate between on/off for battery swap
