EXT 1824G User’s Manual 6. Image Acquisition
EXT 1824G-UM-COM-EN-03 45
6. Image Acquisition
6.1. X-ray Generator Interface
6.1.1. X-ray Exposure Mode
Table 6.1. Exposure Mode
Mode Description
AED Mode
1. The detector detects actual amount of X-rays without any connection to the X-ray
generator, and then performs image acquiring to the extent of image acquisition time
and transmits the image data.
2. No signal used (No need of connector interface cable)
S/W Trigger Mode
1. The detector detects actual amount of X-rays without any connection to the X-ray
generator, and then performs image acquiring to the extent of image acquisition time
and transmits the image data.
2. On the S/W, you should press the Acq. Start button to give the sign for image acquisition
when X-ray is shooting
(No need of connector interface cable)
