DSC PowerSeries Neo

- 19 -
LED 2 Device Status or Error Description
4-blinks
Add Mode (lasts 120 seconds or
until a device is added)
In this mode you can add a device to the local Z-Wave network.
Devices cannot be added to a network if they are already a part
of a network.
2-blinks
Delete Mode (lasts 120 seconds or
until a device is deleted)
In this mode you can delete a device from a Z-Wave network. A
device can only be in one network at a time, and must receive a
“delete” command before it can be learned into a new network.
Solid
Successful add node/remove
node/replication (lasts 60 seconds)
After receiving this signal, leave all devices by the HSPA
module for 1 minute. Locks must be left next to the module for 4
minutes.
Solid with
one blink
Add node attempt failed because
node already in network (lasts 60
seconds)
Device you attempted to add to a network is already in a
network, and must be “deleted” before it can join a new
network.
LED L3 (Yellow)
L3 flashes with every communication between the module and its radio unit in Idle mode, and with every com-
munication with Alarm.com in Connected mode. In PowerSave mode, this LED flashes in unison with LED 2.
LED L4 (Green)
L4 indicates the HSPA signal level as a number of flashes (0 to 5 bars). The number of bars may not corres-
pond to the bars shown on your cell phone. A level of 5 bars is obtained only in the strongest signal conditions.
Signal level is updated every ten seconds if it fluctuates, or every 30 seconds if it is fairly stable. If L4 is not
flashing it indicates one of the following states:
l The module is in PowerSave mode
l The module just powered up
l There is no HSPA coverage in the area. Alarm.com recommends a steady signal level of 2 or higher for
proper operation of the module
Note: In Connected Mode, the LED toggles on and off.
LED L5 (Yellow)
L5 indicates Z-Wave errors. See the table below for more information.
LED 5 Device Status or Error Description
2-blinks
No other nodes are in the network
(lasts until a device is added to the
network)
No devices have been added that can be controlled by the
HSPA module yet. See above for instructions on how to add
devices.
5-blinks
Learn mode error (lasts 60
seconds)
Learn mode error (lasts 60 seconds).
6-blinks
No Home ID present (lasts until the
module connects to Alarm.com
and is configured)
When the HSPA module first connects to Alarm.com it is
configured with a necessary unique network ID.
Various Module States (Modes)
There are four module states, or modes, as described in the following:
