Chapter 4 Programming Descriptions
13
[012] Keypad Lockout
The system can be programmed to ‘lockout’ keypads if a series of incorrect user or installer codes are entered. When lockout is active, all
keypads emit a steady 2-second error tone when a key is pressed. Program the Number of Invalid Codes Before Lockout with the desired
number. Valid entries are from [000] to [255]. Program data [000] to disable the feature. Keypads will remain locked out for the number of
minutes programmed for the Lockout Duration. Valid entries are from [000] to [255].
[11]
System Tamper: Output will activate when any tamper condition is present
[12]
TLM and Alarm: Output will activate if a telephone line trouble is present and then an alarm occurs
[13]
Kissoff: Output will activate for 2 seconds when a valid kissoff is received from the central station
[14]
Ground Start: Output will activate for 2 seconds when the panel attempts to seize the phone line (additional dial tone search must
be programmed in the central station phone number – HEX [D])
[15]
Remote Operation: Output can be activated/deactivated via the DLS software
[16]
For Future Use
[17]
Away Armed Status: Activates when all of the selected partitions are armed in Away mode
[18]
Stay Armed Status: Activates when all of the selected partitions are armed in Stay mode
[19]
Command Output 1: Activates when a [,][7][1] command is entered on the selected partition – Command can be programmed to require
a valid access code and output can be programmed to activate for the time programmed in Section [170] or programmed to latch.
[20]
Command Output 2: Activates when a [,][7][2] command is entered on the selected partition – Command can be programmed to require
a valid access code and output can be programmed to activate for the time programmed in Section [170] or programmed to latch.
[21]
Command Output 3: Activates when a [,][7][3] command is entered on the selected partition – Command can be programmed to require
a valid access code and output can be programmed to activate for the time programmed in Section [170] or programmed to latch.
[22]
Command Output 4: Activates when a [,][7][4] command is entered on the selected partition – Command can be programmed to require
a valid access code and output can be programmed to activate for the time programmed in Section [170] or programmed to latch.
[23]
Silent 24-Hour Input: Changes PGM to a 24-hr Silent zone (PGM2 only)
[24]
Audible 24-Hour Input: Changes PGM to a 24-hr Audible zone (PGM2 only)
[25]
Delayed Fire and Burglary: Functions as a Fire and Burglary output but does not activate until the TX Delay time expires
[26]
Battery Test Output: Output activates for 10 seconds at midnight each day.
[27]
For Future Use
[28]
Holdup Output: Activates when a Holdup Alarm occurs on any assigned partition. Remains active until all assigned partitions have
been armed or disarmed. Will not activate if a Holdup Zone goes into a fault or tamper condition.
[29]
Zone Follower (Zones 1-8):
Active when any of the selected zones are active and deactivates when all of the selected zones are restored.
[30]
Partition Status Alarm Memory: Activates if the selected partition is armed. Output will pulse “one second ON / one second OFF
if an alarm occurs
[31]
Alternate Communicator: Activates when selected system event occurs. If active in the armed state, it remains active until the sys-
tem is disarmed. If activated in the disarmed state, it remains active until a valid access code is entered within the bell cut-off time, or
when the system is armed after the bell cut-off time has expired.
[32]
For Future Use
[33]
For Future Use
[34]
Away Armed with no Zone Bypassed Status: Activates when armed with stay/away zones active and no zones bypassed.
[35]
Zone Follower (Zones 9-16): Active when any of the selected zones are active and deactivates when all of the selected zones are restored.
[36]
Zone Follower (Zones 17-24): Active when any of the selected zones are active and deactivates when all of the selected zones are restored.
[37]
Zone Follower (Zones 25-32): Active when any of the selected zones are active and deactivates when all of the selected zones are restored.
[38]
Zone Follower (Zones 33-40): Active when any of the selected zones are active and deactivates when all of the selected zones are restored.
[39]
Zone Follower (Zones 41-48): Active when any of the selected zones are active and deactivates when all of the selected zones are restored.
[40]
Zone Follower (Zones 49-56): Active when any of the selected zones are active and deactivates when all of the selected zones are restored.
[41]
Zone Follower (Zones 57-64): Active when any of the selected zones are active and deactivates when all of the selected zones are restored.
* See Section [501]-[514] Programmable Output Attributes, PGM Output Option [29] and [35]-[41] Option 8 on 24.
