DSC PowerSeries PC1616 Installation Guide

PowerSeries - PC1616/PC1832/PC1864
36
[101]-[164] Zone Attributes
Zone Attribute Defaults (Y = Option ON; N = Option OFF): Bold entries are opposite for SIA CP-01
* For UL installations, do not change attribute 5 (Force Arming) from the default setting.
Attribute: 1 2 3 4 5 6 7 8 9
ON
Audible Steady Chime Bypass Force* Swing Tx. Delay Wireless Zn Cross Zn
OFF
Silent Pulsed No No No No No No No
Zone Type:
00 Null Zone
NNNNNNN N N
01 Delay 1
YYYYNY
N
NN
02 Delay 2
YYYYNY
N
NN
03 Instant
YYYYNY
N
NN
04 Interior
YYNYNY
N
NN
05 Int. Stay/Away
YYNYYY
N
NN
06 Dly. Stay/Away
YYNYYY
N
NN
07 Dly. 24hr Fire (Hardw.)
YNNNNNN N N
08 Stand. 24hr Fire (Hardw.)
YNNNNNN N N
09 24hr Superv.
NYNNY
NN
NN
10 24hr Superv. Buzzer
NYNYN
NN
NN
11 24hr Burglary
YYNYN
NN
NN
12 24hr Holdup
NYNNN
NN
NN
13 24hr Gas
YNNNN
NN
NN
14 24hr Heating
YNNNN
NN
NN
15 24hr Auxiliary (Medical)
YYNNN
NN
NN
16 24hr Panic
YYNNN
NN
NN
17 24hr Emergency
YYNNN
NN
NN
18 24hr Sprinkler
YYNNN
NN
NN
19 24hr Water
YYNNN
NN
NN
20 24hr Freeze
YYNNN
NN
NN
21 24hr Latching Tamper
YYNNN
NN
NN
22 Momentary Keyswitch
NNNNYNN N N
23 Maintained Keyswitch
NNNNYNN N N
25 Interior/Delay
YYNYNY
N
NN
26 24hr Non-alarm
NNNNYNN N N
29 Auto Verified Fire
YNNNNNN N N
30 Fire Supervisory
NNNNNNN N N
31 Day Zone
YYNYYYY N N
32 Instant Stay/Away
YYNYN
NN
NN
35 24 hr Bell/Buzzer
YYNYNY
N
NN
36 24hr Non Latching Tamper
NYNNNY
N
NN
37 Night Zone
YYNYYY
N
NN
41 24hr Carbon Monoxide
YNNNNNN N N
81 24hr Carbon Monoxide (WLS)
YNNNNNN Y N
87 Dly. 24hr Fire (Wireless)
YNNNNNN Y N
88 Stand. 24hr Fire (Wireless)
YNNNNNN Y N
Attribute: 10 11 12 13 14 15 16
ON
Zone Attributes 10-13 For Future Use NC Loops SEOL DEOL
OFF
Config. Config. Config.
Zone Type:
00 Null Zone
NNNNNNN
01 Delay 1
NNNNNNN
02 Delay 2
NNNNNNN
03 Instant
NNNNNNN
04 Interior
NNNNNNN
05 Int. Stay/Away
NNNNNNN
06 Dly. Stay/Away
NNNNNNN
07 Dly. 24hr Fire (Hardw.)
NNNNNY N
08 Stand. 24hr Fire (Hardw.)
NNNNNY N
09 24hr Superv.
NNNNNNN
10 24hr Superv. Buzzer
NNNNNNN
11 24hr Burglary
NNNNNNN
12 24hr Holdup
NNNNNNN
13 24hr Gas
NNNNNNN
14 24hr Heating
NNNNNNN
15 24hr Medical
NNNNNNN
16 24hr Panic
NNNNNNN
17 24hr Emergency
NNNNNNN
18 24hr Sprinkler
NNNNNNN

DSC PowerSeries PC1616 Specifications

General

Partitions	2
Keypads	Up to 8
Zones	6 on-board
PGMs	2
Power Supply	16.5VAC
Battery Backup	12VDC, 4Ah
