PowerSeries - PC1616/PC1832/PC1864
44
Call Direction Options
[351]-[358] Alarm/Restore Communicator Call Directions
[359]-[366] Tamper/Restore Communicator Call Directions
[347] Miscellaneous Maintenance Reporting Codes [348] Test Transmission Reporting Codes
I_______I_______I
Telephone Number 1 FTC Restore
I_______I_______I
Walk Test End
I_______I_______I
Telephone Number 2 FTC Restore
I_______I_______I
Walk Begin
I_______I_______I
Event Buffer 75% Full Since Last Upload
I_______I_______I
Periodic Test Transmission with Trouble
I___0___I___0__I
DLS Lead IN
I_______I_______I
Periodic Test Transmission
I___0___I___0__I
DLS Lead OUT
I_______I_______I
System Test
I_______I_______I
Zone Fault Alarm
I_______I_______I
For Future Use
I_______I_______I
Zone Fault Restore
I_______I_______I
Delinquency Code
I_______I_______I
General Zone Low Battery Alarm
I_______I_______I
General Zone Low Battery Restoral
I___0___I___0__I
Installer Lead Out
I___0___I___0__I
Installer Lead In
[349] PC5700 Maintenance Reporting Codes (only available in Canada)
I_______I_______I
PC5700 Ground Fault Trouble
I_______I_______I
PC5700 Ground Fault Restore
I_______I_______I
PC5700 TLM Line 1 Trouble
I_______I_______I
PC5700 TLM Line 1 Restore
I_______I_______I
PC5700 TLM Line 2 Trouble
I_______I_______I
PC5700 TLM Line 2 Restore
[350] Communicator Format Options
Default
04 I_______I_______I 1st Telephone Number
04
I_______I_______I 2nd Telephone Number
01 20 BPS, 1400 HZ handshake 05 Pager 08 10 BPS, 2300Hz handshake
02 20 BPS, 2300 HZ handshake 06 Residential Dial** 09-13 For Future Use
03 DTMF CONTACT ID 07 10 BPS, 1400Hz handshake
04 SIA FSK
**Failure to communicate using Residential Dial will not generate a Failed To Communicate Trouble.
Section Partition
Option 1
1st Telephone
Number (Def ON)
Option 2
2nd Telephone
Number (Def OFF)
Option 3
Not Used
(Def OFF)
Option 4
Not Used
(Def OFF)
Option 5
Alt Comm
(Def ON)
Options 6,7,8
Future Use
[351] 1
I________I I________I I________I I________I I________I I________I
[352] 2
I________I I________I I________I I________I I________I I________I
[353] 3
I________I I________I I________I I________I I________I I________I
[354] 4
I________I I________I I________I I________I I________I I________I
[355] 5
I________I I________I I________I I________I I________I I________I
[356] 6
I________I I________I I________I I________I I________I I________I
[357] 7
I________I I________I I________I I________I I________I I________I
[358] 8
I________I I________I I________I I________I I________I I________I
Section Partition
Option 1
1st Telephone
Number (Def ON)
Option 2
2nd Telephone
Number (Def OFF)
Option 3
Not Used
(Def OFF)
Option 4
Not Used
(Def OFF)
Option 5
Alt Comm
(Def ON)
Options 6,7,8
Future Use
[359] 1
I________I I________I I________I I________I I________I I________I
[360] 2
I________I I________I I________I I________I I________I I________I
[361] 3
I________I I________I I________I I________I I________I I________I
[362] 4
I________I I________I I________I I________I I________I I________I
[363] 5
I________I I________I I________I I________I I________I I________I
[364] 6
I________I I________I I________I I________I I________I I________I
[365] 7
I________I I________I I________I I________I I________I I________I
[366] 8
I________I I________I I________I I________I I________I I________I
