DSC PowerSeries PC1616 Installation Guide

Chapter 5 Programming Worksheets
45
[367]-[374] Opening/Closing Communicator Call Directions
[375] System Maintenance Communicator Call Directions
[376] System Test Transmissions Communicator Call Directions
[377] Communication Variables
The values in gray are required for CP-01 compliant systems.
Default
003 I___0__I__0__I___1__I Swinger Shutdown (Alarms and Rest) 001-014 Transmissions; 000=disabled
003
I___0__I__0__I___3__I Swinger Shutdown (Tampers and Rest) 001-014 Transmissions; 000=disabled
003 I___0__I__0__I___3__I Swinger Shutdown (Maintenance and Rest) 001-014 Transmissions; 000=disabled
000 I___0__I__3__I___0__I Communication Delay* 000-255 seconds
030
I___0__I__3__I___0__I AC Failure Communication Delay 001-255 hours/minutes**; 000=disabled
010 I___0__I__1__I___0__I TLM Trouble Delay No. of checks required - valid entries 003 - 255
030 I___0__I__3__I___0__I Test Transmission Cycle (land line) 001-255 days/minutes***
030
I___0__I__3__I___0__I For Future Use
007
I___0__I__0__I___7__I Zone Low Battery Transmission Delay 000-255 days
030
I___0__I__3__I___0__I Delinquency Transmission Cycle 000-255 days/hours****
000
I___0__I__0__I___5__I Communications Cancelled Window 000-255 minutes
* For UL installations, the Entry Delay plus Communication Delay time must not exceed 60 seconds.
**Dependent on programming in [382], Option [6].
***Dependent on programming in [702], Option [3].
****Dependent on programming in [380], Option [8].
[378] Test Transmission Time of Day
Default
9999 I_______I_______I_______I_______I Valid entries are 0000-2359 (9999 to disable)
[379] Periodic DLS Time of Day
Default
FFFF I_______I_______I_______I_______I Valid entries are 0000-2359 (9999 for Random; FFFF to disable)
Section Partition
Option 1
1st Telephone
Number (Def OFF)
Option 2
2nd Telephone
Number (Def OFF)
Option 3
Not Used
(Def OFF)
Option 4
Not Used
(Def OFF)
Option 5
Alt Comm
(Def OFF)
Options 6,7,8
Future Use
[367]
1
I________I I________I I________I I________I I________I I________I
[368]
2
I________I I________I I________I I________I I________I I________I
[369]
3
I________I I________I I________I I________I I________I I________I
[370]
4
I________I I________I I________I I________I I________I I________I
[371]
5
I________I I________I I________I I________I I________I I________I
[372]
6
I________I I________I I________I I________I I________I I________I
[373]
7
I________I I________I I________I I________I I________I I________I
[374]
8
I________I I________I I________I I________I I________I I________I
Section Partition
Option 1
1st Telephone
Number (Def ON)
Option 2
2nd Telephone
Number (Def OFF)
Option 3
Not Used
(Def OFF)
Option 4
Not Used
(Def OFF)
Option 5
Alt Comm
(Def ON)
Options 6,7,8
Future Use
[375]
I________I I________I I________I I________I I________I I________I
Section Partition
Option 1
1st Telephone
Number (Def ON)
Option 2
2nd Telephone
Number (Def OFF)
Option 3
Not Used
(Def OFF)
Option 4
Not Used
(Def OFF)
Option 5
Alt Comm
(Def ON)
Options 6,7,8
Future Use
[376]
I________I I________I I________I I________I I________I I________I

DSC PowerSeries PC1616 Specifications

General

Partitions	2
Keypads	Up to 8
Zones	6 on-board
PGMs	2
Power Supply	16.5VAC
Battery Backup	12VDC, 4Ah
