Chapter 5 Programming Worksheets
47
DLS Downloading
[401] Downloading Option Codes
[402] DLS Downloading Telephone Number (32 Digits)
|____D___|_______|_______|_______|_______|_______|_______|_______|_______|_______|_______|_______|_______|_______|_______|_______|_______|_______|_______|_______|_______|_______|_______|_______|_______|_______|_______|_______|_______|_______|_______|_______|
[403]-[404] DLS Downloading Access Code / Panel ID Code (Enter 6 Hexadecimal Digits)
[405] Answering Machine Double Call Timer [406] Number of Rings to Answer On
Default 060 I_______I_______I_______I (001-255 seconds) Default 000 I_______I_______I_______I (000-255 rings)
[499] Initiate PC-Link Downloading
Enter [499][Installer Code][499]
[501]- [554] Programmable Output Attributes
Program only the following attributes for the PGM options listed. All others will be ignored. PGM options are programmed in [009], [010] & [011].
PGM Attribute Defaults (Y = Attribute ON; N = Attribute OFF; Blank = Attribute not available):
Opt Def ON OFF
1
Answering Machine/Double Call enabled
Answering Machine/Double Call disabled
2
User Can Enable DLS Window
User Cannot Enable DLS Window
3
Call Back enabled
Call Back disabled
4
User Initiated Call Up enabled
User Initiated Call Up disabled
5
Auto Event Buffer Upload enabled
Auto Event Buffer Upload disabled
6
300 Baud Call Up
110 Baud Call Up
7-8
For Future Use
Panel Default [403] Downloading Access Code [404] Panel ID Code
PC1616 161600
|_______|_______|_______|_______|_______|_______| |_______|_______|_______|_______|_______|_______|
PC1832 183200
|_______|_______|_______|_______|_______|_______| |_______|_______|_______|_______|_______|_______|
PC1864 186400
|_______|_______|_______|_______|_______|_______| |_______|_______|_______|_______|_______|_______|
Attribute: 12 3 4 5 678
ON Not
used
Not
used
True
Output
Follows
Timer
Code Req. Not
used
Not
used
Not
used
OFF — — Inverted On / Off No Code
Req.
———
PGM Option
[01] Residential Burglary / Fire Bell Output Y
[02] For Future Use
[03] Sensor Reset [
][7][2] Y
[04] 2-Wire Smoke Support (PGM2 only) Y
[05] System Armed Status Y
[06] Ready To Arm Y
[07] Keypad Buzzer Follower Mode Y
[08] Courtesy Pulse Y
[11] System Tamper (all sources) Y
[12] TLM and Alarm Y
[13] Kiss-off Output YY
[14] Ground Start Pulse YY
[15] Remote Operation (DLS Support) YY
[16] For Future Use Y
[17] Away Armed Status Y
[18] Stay Armed Status Y
[19] Command Output #1, [
][7][1] Y Y Y
[20] Command Output #2, [
][7][2] Y Y N
[21] Command Output #3, [
][7][3] Y Y N
[22] Command Output #4, [
][7][4] Y Y N
To Next Page
