DSE Model 5210 Automatic Start Engine Management and Instrumentation System Operators Manual
24 057-011 5210 OPERATING MANUAL ISSUE 5.1 18/06/2007 AM
NOTE: - The timers are numbered to enable them to be identified when in configuration mode. Some
numbers are reserved so do not appear in the list.
In the following example timer number 2 (‘Start delay’ from the above list) is currently set to 5.0 seconds.
Ie the ‘hour glass’ indicates that it is a timer being displayed. The ‘2’ indicates that it is timer number 2
(Start delay). The current setting is 5.0 (seconds).
