DSE 5210 - 2 Phase, 3 Wire Wiring Diagram

DSE Model 5210 Automatic Start Engine Management and Instrumentation System Operators Manual
42 057-011 5210 OPERATING MANUAL ISSUE 5.1 18/06/2007 AM
16.1.3 2 PHASE, 3 WIRE ( 2 PHASE CENTRE TAP NEUTRAL)
The alternator is 2 phase star connected. The live phases are separated by 180°
