Specifications
19
3.8.2 USB CONNECTION
The USB port is provided to give a simple means of connection between a PC and the DSE8600
series controller.
Using the DSE Configuration Suite Software, the operator is then able to control the module, starting
or stopping the generator, selecting operating modes, etc.
Additionally, the various operating parameters (such as output volts, oil pressure, etc.) of the remote
generator are available to be viewed or changed.
To connect a DSE8600 series module to a PC by USB, the following items are required:
• DSE8600 series module
• DSE 8600 series configuration software
(Supplied on configuration suite software CD or available from
www.deepseaplc.com).
• USB cable Type A to Type B.
(This is the same cable as often used between a PC and a USB
printer)
DSE can supply this cable if required :
PC Configuration interface lead (USB type A – type B) DSE Part No
016-125
NOTE: The DC supply must be connected to the module for configuration by PC.
NOTE: Refer to DSE8600 series Configuration Suite Manual (DSE part 057-119) for further
details on configuring, monitoring and control.
3.8.3 USB HOST-MASTER (USB DRIVE CONNECTION)
Capability to add USB Host facility for USB ‘Pendrive’ type interface for data recording
Connector Type A.
For data logging max maximum size 16Gb.(see viewing the instrument pages)
NOTE: Refer to DSE8600 series Configuration Suite Manual (DSE part 057-119) for further
details on configuring, monitoring and control.
