Description Of Controls
73
5.5 USER CONFIGURABLE INDICATORS
These LEDs can be configured by the user to indicate any one of 100+ different functions based
around the following:-
• Indications - Monitoring of a digital input and indicating associated functioning user’s equipment -
Such as Battery Charger On or Louvres Open, etc.
• WARNINGS and SHUTDOWNS - Specific indication of a particular warning or shutdown condition,
backed up by LCD indication - Such as Low Oil Pressure Shutdown, Low Coolant level, etc.
• Status Indications - Indication of specific functions or sequences derived from the modules
operating state - Such as Safety On, Pre-heating, Panel Locked, Generator Available, etc.
User configurable LEDs
