DSEGenset DSE8610 User Manual

Installation
39
4.1.3 MAGNETIC PICKUP, CAN AND EXPANSION
PIN
No
DESCRIPTION CABLE
SIZE
NOTES
22 Magnetic pickup Positive
0.5mm²
AWG 20
Connect to Magnetic Pickup device
23 Magnetic pickup Negative
0.5mm²
AWG 20
Connect to Magnetic Pickup device
24 Magnetic pickup screen Shield Connect to ground at one end only
25 CAN port H
0.5mm²
AWG 20
Use only 120Ω CAN approved cable
26 CAN port L
0.5mm²
AWG 20
Use only 120Ω CAN approved cable
27 CAN port Common
0.5mm²
AWG 20
Use only 120Ω CAN approved cable
28 DSENet expansion +
0.5mm²
AWG 20
Use only 120Ω RS485 approved cable
29 DSENet expansion -
0.5mm²
AWG 20
Use only 120Ω RS485 approved cable
30 DSENet expansion SCR
0.5mm²
AWG 20
Use only 120Ω RS485 approved cable
MSC
31 Multiset Comms (MSC) Link H
0.5mm²
AWG 20
Use only 120Ω RS485 approved cable
32 Multiset Comms (MSC) Link L
0.5mm²
AWG 20
Use only 120Ω RS485 approved cable
33
Multiset Comms (MSC) Link
SCR
0.5mm²
AWG 20
Use only 120Ω RS485 approved cable
GOV
34 Analogue Governor Output B
0.5mm²
AWG 20
35 Analogue Governor Output A
0.5mm²
AWG 20
AVR
37 Analogue AVR Output B
0.5mm²
AWG 20
38 Analogue AVR Output A
0.5mm²
AWG 20
NOTE: Terminal 36 is not fitted to the 8610 controller
NOTE: Screened cable must be used for connecting the Magnetic Pickup, ensuring that
the screen is earthed at one end ONLY.
NOTE: Screened 120Ω
ΩΩ
Ω impedance cable specified for use with CAN must be used for the
CAN link and the Multiset comms (MSC) link.
DSE stock and supply Belden cable 9841 which is a high quality 120Ω
ΩΩ
Ω impedance cable
suitable for CAN use (DSE part number 016-030)
NOTE: When the module is configured for CAN operation, terminals 22, 23 & 24 should be
left unconnected. Engine speed is transmitted to the 8600 series controller on the CAN link.
Refer to Electronic Engines and DSE Wiring for further information. Part No. 057-004.
NOTE: The Multiset comms (MSC) link Version 5.1+ includes a protocol change to enable
communication with other DSE 55xx and 75xx modules. If one 86xx module is at version 5.0 all
86xx series need to be at 5.0+ to avoid incompatibility.
