Installation
52
4.3.3
2 PHA
SE (L1 & L2) 3
WIRE WITH REST
RICTED
EA
RTH FA
ULT
NOTE: Earthing
the neutral conduct
or ‘before’ the neutral CT
allows th
e module to read
earth faults ‘after’ the CT
only (Restricted to load / do
wnstream of
the CT)
Earthing the neutral cond
uctor ‘after’ the neutral CT
allows t
he module to read earth fault
s
‘before’ the CT
only (Restricted to generator / upstream of
the CT)
51
53
