Firewall configuration for internet access
As modem/routers differ enormously in their configuration, it is not possible for DSE to give a complete
guide to their use with the DSE8610. However it is possible to give a description of the requirements in
generic terms. For details of how to achieve the connection to your modem/router you are referred to
the supplier of your modem/router equipment.
The DSE8610 makes its data available over Modbus TCP and as such communicates over the
Ethernet using a Port configured via the DSE config suite software..
You must configure your modem/router to allow inbound traffic on this port. For more information you
are referred to your WAN interface device (modem/router) manufacturer.
It is also important to note that if the port assigned (setting from software “Modbus Port Number”) is
already in use on the LAN, the DSE8610 cannot be used and another port must be used .
Outgoing Firewall rule
As the DSE8610 makes its user interface available to standard web browsers, all communication uses
the chosen port. It is usual for a firewall to make the same port outgoing open for communication.
Incoming traffic (virtual server)
Network Address and Port Translation (NAPT) allows a single device, such as the modem/router
gateway, to act as an agent between the Internet (or "public external network") and a local (or "internal
private") network. This means that only a single, unique IP address is required to represent an entire
group of computers.
For our DSE8610 application, this means that the WAN IP address of the modem/router is the IP
address we need to access the site from an external (internet) location.
When requests reaches the modem/router, we want this passed to a ‘virtual server’ for handling, in our
case this is the DSE8610 module.
Result : Traffic arriving from the WAN (internet) on port xxx is automatically sent to IP address set
within the configuration software on the LAN (DSE8610) for handling.
NOTE: Refer to DSE8600 series Configuration Suite Manual (DSE part 057-119) for further
details on configuring, monitoring and control.
