DSP TP400 PC - Table E5 - Pc;104-Plus J3 Pin Assignments

E4 158004.B00
PIN J3 ROW A J3 ROW B J3 ROW C J3 ROW D
1 GND/5V KEY N/C Reserved +5V AD00
2 VI/O (+5V) AD02 AD01 +5V
3 AD05 GND AD04 AD03
4 C/BE0# AD07 GND AD06
5 GND AD09 AD08 GND
6 AD11 VI/O (+5V) AD10 M66EN *
7 AD14 AD13 GND AD12
8 +3.3V C/BE1# AD15 +3.3V
9 SERR* GND SB0# * PAR
10 GND PERR# +3.3V SDONE *
11 STOP* +3.3V LOCK# GND
12 +3.3V TRDY# GND DEVSEL#
13 FRAME# GND IRDY# +3.3V
14 GND AD16 +3.3V C/BE2#
15 AD18 +3.3V AD17 GND
16 AD21 AD20 GND AD19
17 +3.3V AD23 AD22 +3.3V
18 IDSEL0 (AD20) GND IDSEL1 (AD21) IDSEL2 (AD22)
19 AD24 C/BE3# V/IO (+5V) IDSEL3 (AD23)
20 GND AD26 AD25 GND
21 AD29 +5V AD28 AD27
22 +5V AD30 GND AD31
23 REQ0# GND REQ1# VI/O (+5V)
24 GND REQ2# * +5V GNT0#
25 GNT1# VI/O (+5V) GNT2# * GND
26 +5V CLK0 GND CLK1
27 CLK2 +5V CLK3 GND
28 GND INTD# +5V RST#
29 +12V *** INTA# INTB# INTC#
30 -12V *** N/C Reserved PME# ** GND/3/3V KEY
NOTES: * These signals are not used on the TP400. They are connected to
+5V through 4k7 resistors.
** This is a reserved pin defined as PME# by DSP Design.
*** These power supply signals are not used on the TP400.
TABLE E5 - PC/104-PLUS J3 PIN ASSIGNMENTS
Pins D1, A30 and D30 of the J3 connector are marked on the PCB silk screen.
