DSP TP400 PC - Power Supply and Fan Connectors; Ethernet Connector; Table E16 - J101 Power Supply Connector Pin Assignments; Table E17 - J102 Power Supply Connector Pin Assignments

158004.B00 E13
E.11 POWER SUPPLY AND FAN CONNECTORS
Power may be brought to the TP400 through connector J101. It is useful in stand-
alone applications. Power may be sent to an optional fan through connector J102.
The power supply and fan connectors are AMP HE14 connectors. The mating types
are available from AMP distributors. In the UK these can be obtained by RS, whose
product codes are: 532-333 (3way), 532-349 (4way) and 532-456 (crimp pins).
Pin 1 of the J101 and J102 connectors can be identified by text reading "1" on the
silk screen near pins 1 of the connectors.
PIN SIGNAL
1 VCC
2 VCC
3 GND
4 GND
TABLE E16 - J101 POWER SUPPLY CONNECTOR PIN ASSIGNMENTS
PIN SIGNAL
1 GND
2 VCC
4 GND
TABLE E17 - J102 POWER SUPPLY CONNECTOR PIN ASSIGNMENTS
E.12 ETHERNET CONNECTOR
Connector J106 is an 8-way SIL header. It carries the Ethernet controller signals to a
remote PCB, the TP400ET, which carries the Ethernet isolation transformer and
RJ45 connector. The connector is from the Hirose DF13 family.
J7 PIN SIGNAL
1 RxD+
2 RxD-
3 VCC
4 GND
5 /LINKLED
6 /LANLED
7 TxD-
8 TxD+
TABLE E18 - J106 ETHERNET CONNECTOR PIN ASSIGNMENTS
