E14 158004.B00
E.13 INTER-BOARD CONNECTORS
J104 has the same pin assignments as J10. Pins 1, 60, 61 and 120 are indicated on
the PCB.
PIN SIGNAL PIN SIGNAL
1 AD1 61 INTD#
2 AD2 62 AD12
3 AD0 63 AD10
4 AD5 64 VCC
5 AD4 65 AD15
6 AD7 66 PAR
7 AD3 67 SERR#
8 C/BE0# 68 DEVSEL#
9 AD6 69 C/BE2#
10 VCC 70 INTA#
11 AD9 71 AD16
12 VCC 72 VCC
13 AD8 73 AD17
14 AD11 74 AD19
15 AD14 75 AD18
16 GND 76 AD22
17 AD13 77 AD21
18 C/BE1# 78 C/BE3#
19 PERR# 79 GND
20 VCC 80 AD26
21 LOCK# 81 STOP#
22 VCC 82 VCC
23 TRDY# 83 AD23
24 GND 84 AD27
25 GND 85 AD24
26 IRDY# 86 GND
27 5530_GNT# 87 AD29
28 VCC 88 AD28
29 AD20 89 AD31
30 AD25 90 5530_REQ#
31 AD30 91 /SUSP
32 FRAME# 92 CPU_RST
33 IRQ13 93 VCC
34 IDE_DATA6 94 SERIALP
35 GND 95 /SUSPA
36 IDE_DATA7 96 GND
37 GND 97 HOLD_REQ#
38 IDE_DATA8 98 INTR
39 VCC 99 GND
40 IDE_ADR2 100 /SMI
41 IDE_DATA11 101 /IDE_IOR0
42 IDE_DATA1 102 /IDE_IOW0
43 GND 103 /IDE_DACK0
44 ETCLK 104 IDE_ADR1
45 GND 105 VCC
46 GNT0# 106 IDE_ADR0
47 REQ1# 107 VCC
48 REQ0# 108 /IDE_CS0
49 GNT1# 109 IDE_DATA10
50 VCC 110 IDE_DATA5
51 VCC 111 /IDE_RST
52 IDE_DATA2 112 /IDE_CS1
53 IDE_DATA15 113 IDE_DATA9
54 IDE_DATA14 114 IDE_DATA4
55 IDE_DREQ0 115 GND
56 IDE_IORDY0 116 IDE_DATA12
57 MEMSCL 117 IDE_DATA3
58 MEMSDA 118 IDE_DATA13
59 GXCLK 119 IDE_DATA0
60 N/C 120 GND
TABLE E19 - J104 AND J10 CONNECTOR PIN ASSIGNMENTS
