E10 158004.B00
SIGNAL NAME SIGNAL FUNCTION
RED0-5 Red Display Data. RED5 is the MSB.
GREEN0-5 GREEN Display Data. GREEN5 is the MSB.
BLUE0-5 Blue Display data. BLUE5 is the MSB.
SHFCLK Shift Clock. Pixel clock for flat panel displays.
LCD_HSYNC Flat panel horizontal sync signal.
LCD_VSYNC Flat panel vertical sync signal.
ENABLE Display Enable or composite sync signal.
ENAVDD Power sequencing control for VDD. High to switch on power.
ENABKL Power control for backlight inverter. High to switch on power.
TABLE E12 - FUNCTION OF FLAT PANEL SIGNALS
E.8 USB CONNECTOR
Connector J9 is an 8-way SIL header. It carries the USB signals to a remote PCB, the
TP300USB, which carries the USB connectors. The connector is from the Hirose
DF13 family.
J9 PIN SIGNAL
1 Port 1 Data -
2 Port 1 Data +
3 Port 1 VCC
4 Port 1 GND
5 Port 2 VCC
6 Port 2 GND
7 Port 2 Data -
8 Port 2 Data +
TABLE E13 - J9 USB CONNECTOR PIN ASSIGNMENTS
