3.4. Power Requirements
The SLICE system runs on DC power.
To calculate the rough power needs for a particular system, use the information
below:
POWE R!RE QUIREMENTS!
10!V!POWER! INPUT /5! V!SENSOR! EXCITATION! IDLE! RECORDING!
BASE!SLICE! 40 !mA! 110!mA!
BRIDGE!SLICE! ! 2!mA! 55! mA!
SENSOR!LOAD!(350!o hm/5!V!SENS OR! EXCITATION!)! 0!mA! 50!mA!
SINGLE!STACK!POWER!CONSUMPTION!AT!5!!V!SENS OR!
E XCITATION!!
TOTAL!
BASE!(QTY )! 1!
BRIDGE!(QTY)! 2!
SENSOR!LOAD!(%!of! 350! ohm)! 100!
IDLE!C URRENT! ! 44!mA!
IDLE!P OWER! ! 330! mW!
RECORD!CURRENT! ! 320! mA!
RECORD!POWER! ! 2400! mW!
