DTS SLICE NANO - Appendix E: SLICE Distributor

APPENDIX E - SLICE Distributor support@dtsweb.com
August 2009 ©Diversified Technical Systems, Inc. - All Rights Reserved
Status LED Action
No input power
Power input detected; system OFF
Power input detected; system ON
Armed in recorder mode;
not collecting data
Collecting data
Torque specs: * 19.8 in-lb (2.24 Nm); ** 9.6 in-lb (1.1 Nm)
Specifications may be revised without notice.
53,98 mm (2.125 in)
49,4 mm (1.945 in)
4,99 mm
(0.197 in)
! 4,27 mm diam
(0.168 in) x2
mounting thru holes
Use M4* or
6-32** screws
35,94 mm
(1.415 in)
13,46 mm
(
0.530 in
)
53
,
98 mm
(
2.125 in
)
48
,
98 mm
(
1.929 in
)
43
,
99 mm
(
1.732 in
)
4,19 mm
(
0.165 in
)
24,89 mm
(0.98 in)
momentary ON/OFF
push button switch
see pin assignments
for AUX connector
functions
see pin assignments for
SYS connector functions
Optional 802.11 b/g wireless
support (10-32 antenna port)
SLICE system connectors; to
UP port on SLICE MICRO
®
or
SLICE NANO
®
(supports
<
10 A per connector)
