REV:!3!MAY!2010!
5.!!SLICE&CONNECTION&OPTIONS&!
S‐EOC:&&SLICE&END&OF&CHAIN&&
USB!Communication!
7!to!15!VDC!power!input!
Supports!up!to!!4!STACKS!in!daisy‐chained!
configuration!
S‐SSI:&&SLICE&SYSTEM&INTERFACE&
USB!Communication!
9!to!20!VDC!power!input!
Supports!up!to!4!STACKS!in!daisy‐chained!
configuration!
Recommended!for!multi‐stack!configura‐
tions!
!
S‐DB:&&SLICE&DISTRIBUTOR&
Ethernet!communication!
9!to!20!VDC!power!input!
Supports!up!to!!16!STACKS!!in!4!daisy‐
chained!configuration!
Recommended!for!large!configurations!
!
6.!!BATTERY&OPTIONS&!
RECHARGEABLE&9.6&V&NiMH&BATTERIES&
Allows!up!to!40!min!runtime!with!6!channel!!
SLICE!System!
Package'of'4'batteries'ensures'you’ll'always'
have!back‐ups!ready!to!use!
RECHARGEABLE&11.1&VDC&LiPo&BATTERIES&
Available!in!3!capacities:!
! ‐!!2200!mAh!!!
! ‐!4400!mAh!
! ‐!6600!mAh!
POWER&REQUIREMENTS& ! !
10!V!POWER!INPUT/5!V!SENSOR!EXCITATION! IDLE! RECORDING!
BASE!SLICE! 40!mA! 110!mA!
BRIDGE!SLICE!! 2!mA! 55!mA!
SENSOR!LOAD!(350!ohm/5!V!SENSOR!EXCITATION!)! 0!mA! 50!mA!
SINGLE&STACK&POWER&CONSUMPTION&AT&5&&V&SENSOR&
EXCITATION&&
TOTAL& !
BASE!(QTY)! 1! !
BRIDGE!(QTY)! 2! !
SENSOR!LOAD!(%!of!350!ohm)! 100! !
IDLE!CURRENT!! 44!mA! !
IDLE!POWER!! 330!mW! !
RECORD!CURRENT!! 320!mA! !
RECORD!POWER!! 2400!mW! !
SLICE&B!"#$%&'(!)*#&
SLICE&NANO&STACK&BATTERY&
Charges!whenever!input!power!is!connected!to!!NANO!BASE!
~15!min!from!complete!discharge!to!full!charge!(10.5!VDC,!100!mA,!
at!input!connector!on!!NANO!BASE!
