C
a
b
l
e
Ins
t
a
ll
a
t
i
on R
e
c
omm
e
nd
a
t
i
ons
• Flat braided ground cable has lower impedance than typical round
wires and hence makes a better ground connection.
• Never assume that connections are good until you check them with
an ohmmeter. Should be <1# for short runs or <5# for long runs.
• Ground cables inside test dummies should be braided type with a 12-
gage equivalent size.
• Ground cables from a test article or vehicle to the SLICE Stack should
be braided strap type with a 15-gage equivalent size.
• The cable from a test article or vehicle to the Earth connection
should be large enough to create an a low impedance connection
given the distance between Earth connection and test vehicle. 8 to
12
• If braided c able is not available, any ground wire is better than none!
© 2009-2010 DTS Principles of Dynamic Data Acquisition
