DTS SLICE NANO - Page 83

M e a sur i ng L a rg e Vo l t a g e s - Ex a mp l e
(5V) +EX
1
10K
Lemo Plug
+ SIG
3
4
- SIG
Amp li f i e r
_
+
10K
10K
10K
R
External
Voltage
4
2
10K
R
SLICE Bridge
(0V) - EX
Resistance
R
Approx MAX
External Voltage
Vm a x
* Sensitivity
mV/V
*
Sensitivity calculation … .
95. 3K
49. 850
+ / -40V
150K
32. 258
+ / -60V
45. 3K
99. 404
+ / -20V
Sensitivity
calculation … .
5
(5 + R)
( )
X 1000
