Seat lock
Opening
Insert the key (1) in lock, turn clockwise while
pressing down at the latch to help release the pin.
Remove the seat (2) pulling it backwards until sliding
it out of the front retainers.
Closing
Make sure all parts are correctly laid out and secured
in the underseat compartment.
Slide the front ends (A) of the seat bottom
underneath the retainer (B) of the tank.
Fig. 92
Fig. 93
146
