Parameter setting and displaying
Upon switching on, the instrument panel activates
the rev counter that increases from 0 to 11000 and
decreases up to 0; the Dot-Matrix shows the moving
indication "DUCATI HYPERMOTARD"; warning lights
turn on one after the other starting from the external
side to the internal side.
After the check, the "main" information displayed on
the instrument panel are Odometer (TOT), engine
coolant temperature and "Riding Mode".
1
2
Fig. 6
29
